eXmark MN TT4816BV Upper Handles And Controls

#
Part #
Item
Price
Qty
Add
1
1-303020
GRIP-LEVER
$2.98
3
1-805260
3/8 Std. flatwasher

product not available CALL FOR AVAILABILITY

$0.01
4
1-800295
3/8-16 X 1 3/4 HH capscrew

product not available CALL FOR AVAILABILITY

$0.01
5
1-413088
Spacer
$11.99
6
1-804257
3/8-16 Nylock nut

product not available CALL FOR AVAILABILITY

$0.01
7
1-806003
PIN-COTTER
$1.81
8
1-413293
Rod, blade engagement
$72.59
9
1-413279
Turnbuckle, 3/8-16 SS
$46.19
10
1-804507
Nut, 3/8-16 hex

product not available CALL FOR AVAILABILITY

$0.01
11
1-412183-03
LEVER-LH
$80.29
12
1-803322
SCREW-SET
$1.55
13
1-303365
BUSHING-NYLON
$5.75
14
1-322192-03
WLD,ROD OPC
$43.99
15
1-303363
SPRING-EXTENSION
$7.07
16
1-412185-03
LEVER-RH
$75.89
17
1-807513
Bolt-Carriage #10-24 x 1/2
$2.98
18
1-513592
Knob-Ball Red
$7.07
19
1-323129
Cable, control (throttle)
$34.23
20
1-804252
10-24 Nylock nut

product not available CALL FOR AVAILABILITY

$0.01
21
1-412140
Handle weldment, upper

product not available CALL FOR AVAILABILITY

$0.01
22
1-303097
Grip-Handle
$3.72
23
1-413152
BUSHING-SLEEVE
$2.98
24
1-412159
Lever, drive (LH)

product not available CALL FOR AVAILABILITY

$0.01
25
1-603749
Bushing-Lever, Drive
$8.87
26
1-800256
Screw, 1/4-20 x 1-1/2

product not available CALL FOR AVAILABILITY

$0.01
27
1-809012
1/4-20 Whizlock Nut

product not available CALL FOR AVAILABILITY

$0.01
28
1-804255
1/4-20 Nylock nut

product not available CALL FOR AVAILABILITY

$0.01
29
1-805256
1/4 STD. Flatwasher

product not available CALL FOR AVAILABILITY

$0.01
30
1-303435
Washer-Spring Disc 1/4
$1.81
31
1-612168
RH LATCH and GRIP ASM

product not available CALL FOR AVAILABILITY

$0.01
32
1-800257
1/4-20 x 1 3/4 HH capscrew

product not available CALL FOR AVAILABILITY

$0.01
33
1-303019
GRIP-LATCH
$2.98
34
1-809007
3/8-16 Whizlock Nut

product not available CALL FOR AVAILABILITY

$0.01
35
1-303327
XREF 98-5975

product not available CALL FOR AVAILABILITY

$0.01
36
1-800292
3/8-16 x 1 HHCS

product not available CALL FOR AVAILABILITY

$0.01
37
1-613055
Pin-Clevis
$9.47
38
1-800277
Screw, 5/16-18 x 2

product not available CALL FOR AVAILABILITY

$0.01
39
1-603716
Washer-Friction
$5.75
40
1-323244
Washer-Friction
$8.03
41
1-603730
PLATE-LEVER, SHIFTER
$38.49
42
1-602733
Lever-Shift

product not available CALL FOR AVAILABILITY

$0.01
43
1-603175
Knob-Ball
$12.09
44
1-804256
XREF 3296-29

product not available CALL FOR AVAILABILITY

$0.01
45
1-323245
Spring-Compression
$7.07
46
1-805257
Washer, 5/16 (SAE)

product not available CALL FOR AVAILABILITY

$0.01
47
1-800251
SCRW,CAP HH 1/4-20X5/8

product not available CALL FOR AVAILABILITY

$0.01
48
1-413225
Rod, speed control
$15.39
49
1-804758
Nut, jam 5/16-24

product not available CALL FOR AVAILABILITY

$0.01
50
1-303105
Yoke-Adjustable
$13.19
51
1-808280
Pin-Clevis 5/16 x 1 49/64
$2.98
52
1-513508
CAP-FUEL
$27.49
53
1-413179
Tank, Fuel Intermediate

product not available CALL FOR AVAILABILITY

$0.01
54
1-633023
Stud-Fuel Tank
$7.07
55
1-633349
Spring-Compression
$5.75
56
1-805005
Washer-Lock 5/16 Heavy
$1.55
57
1-800271
5/16-18 x 3/4 HH capscrew

product not available CALL FOR AVAILABILITY

$0.01
58
1-513645
BUSHING-VALVE, FUEL

product not available CALL FOR AVAILABILITY

$0.01
59
1-543277
ELBOW-TANK, FUEL
$12.09
60
1-303077
Clamp-Fuel Line
$1.55
61
1-603955
HOSE-FUEL
$5.75
62
1-603770
Valve-Fuel
$9.11
63
1-603776
HOSE-LINE, FUEL
$5.39
64
1-303197
FILTER-FUEL

product not available CALL FOR AVAILABILITY

$0.01
65
1-303471
LINE-FUEL
$8.51
66
1-303308
CLAMP-HOSE
$5.39
67
1-403121
SWITCH & KEY (INCLUDES NUT & WASHER)
$23.09
68
1-403118-01
Bracket, key switch

product not available CALL FOR AVAILABILITY

$0.01
69
1-803028
XREF 3290-500

product not available CALL FOR AVAILABILITY

$0.01
70
1-323229
CLIP-LOOM
$3.23
71
1-303287
Tie-Cable 5 1/2 (Small)
$1.55
72
1-513051
Switch-N.O.
$19.79
73
1-800252
1/4-20 x 3/4 HH capscrew

product not available CALL FOR AVAILABILITY

$0.01
74
1-633181
Plate-Tapped
$7.07
75
1-413146
Harness, wiring
$92.99
76
1-323430
SWITCH-MODULE-INTERLOCK
$129.99
77
1-804002
Nut-SQH
$1.42

1-413428
Cable, throttle (15hp Kaw)
$67.09

1-633696
THROTTLE CABLE ASM
$63.79

1-412161
Lever, drive (RH)

product not available CALL FOR AVAILABILITY

$0.01

1-612167
LH LATCH GRIP ASM

product not available CALL FOR AVAILABILITY

$0.01

1-543649
Hose, fuel 7.0 (Kaw)

product not available CALL FOR AVAILABILITY

$0.01

1-303022
HOSE-FUEL
$5.39

1-603954
HOSE-LINE, FUEL
$9.95

1-603511
Key-Ignition
$2.72

1-413208
Harness, wiring
$89.99

1-413323
Harness, wiring

product not available CALL FOR AVAILABILITY

$0.01

1-413430
Harness, wiring (17hp Kaw)

product not available CALL FOR AVAILABILITY

$0.01

1-840022
Pro-Lock,Nut Type (.5cc Tube)
$18.69

1-840023
Prolock, retaining type
$19.79
