Woods Woods 312-1 Batwing Rotary Cutter Center Frame (Rear) Assembly

#
Part #
Item
Price
Qty
Add
1
17083
Attitude rod

product not available CALL FOR AVAILABILITY

$0.00
2
33204
Transport bar

product not available CALL FOR AVAILABILITY

$138.16
3
33203
TRANSPORT TUBE WA

product not available CALL FOR AVAILABILITY

$185.37
4
10475
3-1/2X8 HYD CYLW
$274.00
5
8347
PIN, HDLS 1.00 X 5.08
$21.90
6
23650
Ratchet adjustment link

product not available CALL FOR AVAILABILITY

$0.00
7
24098
1-1/4CYL STRK CN
$40.68
9
10417RP
214ETC, HT ADJ PIVOT BLK
$36.84
10
32496
1/2 x 2-1/2 x 8-5/8 Lug

product not available CALL FOR AVAILABILITY

$58.63
11
33114
Single wheel spring yoke tube (See note 5)

product not available CALL FOR AVAILABILITY

$1,220.00
14
8322
PIN HDLS .75 X 2.58

product not available CALL FOR AVAILABILITY

$8.81
31
1285
PIN, COTTER 1/4 X 1-1/2
$1.44
32
765
NUT, LOCK, 1/2 NC ZP
$3.40
33
24576
HHCS 1/2 NC X 1-3/4 GR5 ZP
$2.52
34
6239
NUT, LOCK, 5/8 NC
$2.31
35
986
BOLT, HEX 5/8 NC X 2-3/4 HT
$3.75
36
2371
NUT, LOCK, 3/4 NC ZP
$3.23
37
30068
BOLT, HEX 3/4 NC X 2-1/2 GR5 Z
$5.40
38
14334
BOLT, HEX 3/4 NC X 3 GR5
$4.40
39
1863
WASHER, FLAT, 1 SAE ZP
$2.13
40
3626
NUT HEX 1-14 UNS
$3.31
41
3132
NUT, HEX, 1 NC ZP
$7.38
