Woods Woods 60-4 Single Spindle (8/92) Single Spindle Cutter Main Frame Assembly

#
Part #
Item
Price
Qty
Add
1
11090
Tongue

product not available CALL FOR AVAILABILITY

$0.00
2
29674
Front 2/3 of 3-joint drive L14R

product not available CALL FOR AVAILABILITY

$0.00
3
9104
Wheel yoke

product not available CALL FOR AVAILABILITY

$0.00
4
5532
Wheel yoke arm

product not available CALL FOR AVAILABILITY

$0.00
5
529
RIM 15 X 4-1/2 4
$82.04
6
4675
WHL, 400X8 LAMINATED TIRE
$247.93
7
23790
JACK, PARKING SWIVEL 2000LBS
$172.80
8
7668RP
60-4 ETC H FRAME ASY
$126.34
9
11066
60-4 ETC RR DR SHFT SHLD

product not available CALL FOR AVAILABILITY

$214.54
9
29671
Drive shaft shield, 56-3/4 inch long

product not available CALL FOR AVAILABILITY

$163.90
10
15133
HT ADJ CRNK ARMW/PIN39.5

product not available CALL FOR AVAILABILITY

$282.21
11
11174
60-4 ETC LEVELER ROD

product not available CALL FOR AVAILABILITY

$136.51
12
11097
Shield support

product not available CALL FOR AVAILABILITY

$137.94
12
29672
Shield support (with bent legs)

product not available CALL FOR AVAILABILITY

$272.30
13
6747
SHLD STRAP

product not available CALL FOR AVAILABILITY

$24.26
14
10417RP
214ETC, HT ADJ PIVOT BLK
$36.84
15
5895RP
HT ADJM PIVOT NUT

product not available CALL FOR AVAILABILITY

$500.92
16
7035
PIPE, 1/2 SCHEDULE 40 X 3.56
$17.39
17
11190
PIPE 3/4 SCH 80X 0.75

product not available CALL FOR AVAILABILITY

$51.99
18
15134
PIN SPIROL .25 X 1.00
$2.31
31
195
STRT 1/8P THRD G FITTING
$1.90
32
1256
3/16 X 1, COTTER PIN
$1.19
33
6128
1/4 NC Lock nut (See note 30)

product not available CALL FOR AVAILABILITY

$0.00
34
1282
SCREW, ROUND HEAD SLOTTED 1/4N
$0.67
35
1285
PIN, COTTER 1/4 X 1-1/2
$1.44
36
11880
5/16X 1-3/4 SPIROL PIN
$3.54
37
839
BOLT, HEX 3/8 NC X 1 GR5 ZP
$1.54
38
855
WASHER, LOCK, 1/2 ZP
$1.44
39
1093
NUT, HEX HEAVY 1/2 NC ZP
$1.54
40
12305
BOLT, HEX 1/2 NC X 5-1/2 GR5
$3.23
41
W404
PIN, CLV 1/2 X 5-3/4 HT
$18.64
42
1286
WASHER, LOCK, HEAVY ZP
$1.72
43
692
WASHER, FLAT, 5/8 STD ZP
$1.72
44
230
NUT, HEX, 5/8 NC PLATD
$1.72
45
4548
BOLT, HEX 5/8 NC X 1-3/4 GR5 Z
$2.31
46
12274
BOLT, HEX 5/8 NC X 2-1/4 GR5
$3.54
47
11854
BOLT, HEX 5/8 NC X 2-1/2
$5.06
48
5777
PIN CLV 5/8 X 2-1/4
$15.03
49
W8317
PIN CLV 5/8 X 5-21/32
$36.32
50
11081
BSHG 5/8 X 7/8 X 11/16 HT
$42.53
51
2371
NUT, LOCK, 3/4 NC ZP
$3.23
52
7969RP
SLV 1-1/64X 1-3/4 X 3/4
$43.91
53
11099
1-1/4 X 3-1/4 LONG PIN

product not available CALL FOR AVAILABILITY

$37.38
54
11100
1-5/16 x 1-3/4 x2-1/8 Sleeve

product not available CALL FOR AVAILABILITY

$108.46
