Woods Woods L59JD85 Undermount/Mid-mount Rotary Cutter Mounting Frame Assembly

1

18336

K PLUG 1-1/16-121DSAETHD

$3.04

2

30616

4/0 TWST LINK CHAIN 96

$44.79

3

6696RP

CHAIN IDLER CASTING

$36.78

4

28113

Front lift bracket assembly

product not available CALL FOR AVAILABILITY

$109.01

5

23928

LU306K22 PUSH CH

$70.60

5

18241

59LBPUSH CHNL W/CLVSBARW

$137.34

6

27580

Crosswise rear support

product not available CALL FOR AVAILABILITY

$0.00

7

28106

Right push bracket

product not available CALL FOR AVAILABILITY

$253.60

8

28107

Left push bracket

product not available CALL FOR AVAILABILITY

$253.60

9

28100

Idler bracket assembly

product not available CALL FOR AVAILABILITY

$232.50

11

4336

V GROOVE IDLR W BRG

$81.23

12

6095

BRG-BALL .626 ID X 1.85 OD

$33.79

13

27803

Rear lift bracket

product not available CALL FOR AVAILABILITY

$0.00

14

27802

Lift bar clamp

product not available CALL FOR AVAILABILITY

$0.00

15

24803

304K RR KEYHOL LIFT LUGW

$50.83

16

28115

L59 JD ETC SHIELD ASY W

$190.75

17

4001

BSHG P1 1-3/8 6 SPLND

$56.11

18

10830

1TB 18.4 SHV OFFSET HUBW (See note 11)

product not available CALL FOR AVAILABILITY

$0.00

19

23636

V-BELT GUIDE

$11.93

20

11466

W213 V-BELT L59U

$183.56

20

10859

W208 V-BELT L59 D10 ETC

$189.63

20

23990

W194 V-BELT L306H284ETC

$155.14

20

3652

W189 V-BELT

$136.04

30

1256

3/16 X 1, COTTER PIN

$1.19

31

18270

PIN, SAFETY 3/16 X3-1/4

$1.19

32

14562

BOLT, HEX 5/16 NC X 1 GR5

$1.72

33

27851

3/8 x 1/2 x 1/4 Sleeve HT (See note 12)

product not available CALL FOR AVAILABILITY

$7.80

34

839

BOLT, HEX 3/8 NC X 1 GR5 ZP

$1.54

35

920

HHCS, 3/8 NC X 1-3/4 GR5 ZP

$3.19

36

14350

NUT, LOCK FLANGE 3/8 NC

$1.72

37

1287

NUT WING 3/8 NC

$1.72

38

3504

SLV 1/2 X 5/8 X 1-1/16 HT

$3.91

39

24537

WSHR .5ID 1.375OD .375THICK

$8.02

40

948

1/2 NC x 2 inch Hex head cap screw (See note 3)

product not available CALL FOR AVAILABILITY

$0.00

41

409

PIN, CLEVIS 1/2 X 2

$6.75

42

3598

WASHER, FLAT, 1/2 SAE ZP

$1.90

43

855

WASHER, LOCK, 1/2 ZP

$1.44

44

11900

NUT, LOCK FLANGE 1/2 NC

$1.90

45

29302

HHCS M12-1.75P X 50MM

$6.03

46

23030

HHCS M14-2.0P X 35MM

$3.62

47

4097

PIN, CLV 5/8 X 1-1/2

$3.74

48

410

PIN CLV 5/8 X 1-3/4

$3.83

49

5079

5/8 NC x 2-1/4 carriage bolt

product not available CALL FOR AVAILABILITY

$0.00

50

692

WASHER, FLAT, 5/8 STD ZP

$1.72

51

1286

WASHER, LOCK, HEAVY ZP

$1.72

52

230

NUT, HEX, 5/8 NC PLATD

$1.72

53

2688

5/32 HAIR PIN COTTER

$2.52

54

28118

3/4 x 4 Drilled pin (See note 27)

product not available CALL FOR AVAILABILITY

$220.10
