Woods Woods L59KD-1 KUBOTA D20 & L200 Undermount/Mid-mount Rotary Cutter Mounting Frame Assembly

#
Part #
Item
Price
Qty
Add
1
18336
K PLUG 1-1/16-121DSAETHD
$3.04
2
30616
4/0 TWST LINK CHAIN 96
$44.79
3
6696RP
CHAIN IDLER CASTING
$36.78
4
6674RP
LIFT CLEVIS SHORT W
$35.80
5
12030
Chain lift bracket

product not available CALL FOR AVAILABILITY

$0.00
6
17482
Push arm bracket

product not available CALL FOR AVAILABILITY

$0.00
7
17480
Rear lift angle

product not available CALL FOR AVAILABILITY

$0.00
8
17485
Idler bracket assembly

product not available CALL FOR AVAILABILITY

$0.00
9
1505RP
SHV 7.40 IB H
$109.53
10
17490
H1, 1-3/8 6B splined bushing With bolts (See note 12)

product not available CALL FOR AVAILABILITY

$18.00
11
17495
V-belt shield for L200, L200A & L210

product not available CALL FOR AVAILABILITY

$0.00
12
6672
BRACKET
$48.27
13
5762
BOLT EYE 3/8 NC X 3-1/4 OPEN
$31.06
15
4336
V GROOVE IDLR W BRG
$81.23
16
6095
BRG-BALL .626 ID X 1.85 OD
$33.79
17
3492
W172 V-BELT-F4501 59CL CF
$129.10
18
18338
Lift angle spacer block (See note 1)

product not available CALL FOR AVAILABILITY

$0.00
19
18335
7GAX 1-3/4X 2-9/16 LUG W
$9.51
30
2688
5/32 HAIR PIN COTTER
$2.52
31
1256
3/16 X 1, COTTER PIN
$1.19
32
2457
BOLT, HEX, 1/4NC X 3/4, GR5
$1.19
33
5295
5/16 NC x 1 inch Hex head cap screw (See note 9)

product not available CALL FOR AVAILABILITY

$0.00
34
14139
NUT, LOCK FLANGE 5/16 NC
$3.13
35
6697
BOLT, CARRIAGE 3/8 NC X 1 GR
$1.72
36
835
NUT, HEX 3/8 NC ZP
$1.72
37
838
WASHER, LOCK, 3/8 ZP
$1.44
38
17479
HHCS M12-1.50P X 35MM
$6.14
39
948
1/2 NC x 2 inch Hex head cap screw (See note 3)

product not available CALL FOR AVAILABILITY

$0.00
40
11900
NUT, LOCK FLANGE 1/2 NC
$1.90
41
409
PIN, CLEVIS 1/2 X 2
$6.75
42
5836
BOLT, CRG 5/8NC X 2-1/2 GR5 Z
$2.74
43
230
NUT, HEX, 5/8 NC PLATD
$1.72
44
1286
WASHER, LOCK, HEAVY ZP
$1.72
45
692
WASHER, FLAT, 5/8 STD ZP
$1.72
46
4097
PIN, CLV 5/8 X 1-1/2
$3.74
47
5777
PIN CLV 5/8 X 2-1/4
$15.03
48
16086
M15 Metric fine thread x 1-1/4 HHCS (For L200 & L210)

product not available CALL FOR AVAILABILITY

$0.00
49
16087
HHCS M14-1.50P X 35MM
$8.52
