Woods Woods M60B AC-1 Single Spindle Single Spindle Cutter Main Assembly

#
Part #
Item
Price
Qty
Add
1
4601
Frame only

product not available CALL FOR AVAILABILITY

$0.00
2
6010
Complete drive (1-3/8 QD yoke) (See note 3)

product not available CALL FOR AVAILABILITY

$0.00
2
6008
Complete drive (1-3/8 QD yoke) (See note 1)

product not available CALL FOR AVAILABILITY

$0.00
3
4377
Front shield

product not available CALL FOR AVAILABILITY

$0.00
4
4288
inchU inch frame

product not available CALL FOR AVAILABILITY

$0.00
5
4286
Right pin arm

product not available CALL FOR AVAILABILITY

$0.00
6
4010
Chain

product not available CALL FOR AVAILABILITY

$0.00
7
4287
Left pin arm

product not available CALL FOR AVAILABILITY

$0.00
8
1791
SLEEVE, .625 X 1.00 X .563 HT
$2.52
9
4291
Bracket

product not available CALL FOR AVAILABILITY

$0.00
10
4292
Brace

product not available CALL FOR AVAILABILITY

$0.00
11
4645
Right skid

product not available CALL FOR AVAILABILITY

$0.00
12
4342
Gear box shield

product not available CALL FOR AVAILABILITY

$0.00
13
4326
Gear box (See note 3)

product not available CALL FOR AVAILABILITY

$0.00
14
3444RP
ACCESS HOLE COVER
$22.22
15
4729
Tailwheel (See note 4)

product not available CALL FOR AVAILABILITY

$0.00
16
4746
Rear shield

product not available CALL FOR AVAILABILITY

$0.00
17
4646
Left skid

product not available CALL FOR AVAILABILITY

$0.00
20
839
BOLT, HEX 3/8 NC X 1 GR5 ZP
$1.54
21
835
NUT, HEX 3/8 NC ZP
$1.72
22
838
WASHER, LOCK, 3/8 ZP
$1.44
23
1287
NUT WING 3/8 NC
$1.72
24
3379
BOLT, HEX 1/2 NC X 1-1/2 GR5 Z
$2.93
25
24576
HHCS 1/2 NC X 1-3/4 GR5 ZP
$2.52
26
948
1/2 NC x 2 inch Hex head cap screw (See note 3)

product not available CALL FOR AVAILABILITY

$0.00
27
323A
1/2 NC x 2-1/4 Hex head cap screw (See note 15)

product not available CALL FOR AVAILABILITY

$0.00
28
639
1/2 x 2-1/2 Hex head cap screw

product not available CALL FOR AVAILABILITY

$0.00
29
1093
NUT, HEX HEAVY 1/2 NC ZP
$1.54
30
855
WASHER, LOCK, 1/2 ZP
$1.44
31
854
WASHER, FLAT, 1/2 STD ZP
$1.44
32
738
5/8 NC x 1-1/2 Hex head cap screw

product not available CALL FOR AVAILABILITY

$0.00
33
614
5/8 NC x 1-3/4 Hex head cap screw (See note 35)

product not available CALL FOR AVAILABILITY

$0.00
34
2855
BOLT, CARRIAGE 5/8 NC X 2
$3.13
35
230
NUT, HEX, 5/8 NC PLATD
$1.72
36
1286
WASHER, LOCK, HEAVY ZP
$1.72
37
692
WASHER, FLAT, 5/8 STD ZP
$1.72
