Woods Woods M72I-1 Single Spindle (3/90) Single Spindle Cutter Main assembly

#
Part #
Item
Price
Qty
Add
1
11122
72-1ETC SKID SHOE W HDW
$308.13
2
11141
72-1 ETC LT SIDE FRM ASY
$237.11
3
9835
Frame (See note 1)

product not available CALL FOR AVAILABILITY

$0.00
4
11041
3/8 x 3/8 x 2-7/8 Key

product not available CALL FOR AVAILABILITY

$0.00
5
29269
1-5/8 CLMP CROSS BAR CMP
$400.20
5A
29272
WASHER, 1-5/8ID 2-1/4OD 7GATHI
$14.17
6
24652RP
WSHR 1-1/8 HEX BOWED
$4.79
7
W7828
WASHER, 3/4 X 2-1/2 X 1/4 HT
$11.72
8
11204
SHIM 13/16ID .010THICK
$3.80
9
32602
PIN, BLADE 2.39
$28.82
10
23310
Double edge hook (See note 4)

product not available CALL FOR AVAILABILITY

$0.00
10
6323KT
KIT, BLADE, 6323 STD
$197.09
10
6323
3/8 x 4 x 30 CCW Formed blade

product not available CALL FOR AVAILABILITY

$0.01
11
10520RP
18GA 1-1/2 BLD PIN SHIM
$6.98
12
5523RP
SPACER
$4.61
13
32603
PLATE, KEYHOLE SPECIAL
$11.23
14
32604RP
BLADE PIN LOCK CLIP SPEC
$4.39
15
23900
CAT 1 MTG PIN 5-1/4 LONG
$15.08
16
29281
SLV 7/8 X 1-1/8 X 19/32 HT
$10.83
17
9304
6SCLCH1.375B35N-1-3/16SQ
$642.00
18
W7363
TUBLR SHFT - JT 35N

product not available CALL FOR AVAILABILITY

$2,058.98
19
10521
CHAINA ASSEM
$73.37
20
7906RP
LWR CHECK CHAIN BRKT
$27.99
21
18048
CHAIN KIT, 3/8 CHAIN 32-LINK/
$76.31
22
11068
M60P-4 A FRM HAL
$53.95
23
7142
1/4 X 1/4 X 2 KEY
$5.90
24
11050
72-1 ETC GEAR BOX 1 1
$1,450.00
25
11069
Top lift arm assembly

product not available CALL FOR AVAILABILITY

$213.00
26
23793
M60-4ETC CLUTCH DRV SHLD
$75.05
27
5546
Pivot arm

product not available CALL FOR AVAILABILITY

$103.91
28
3444RP
ACCESS HOLE COVER
$22.22
29
9629
Tailwheel (See note 7)

product not available CALL FOR AVAILABILITY

$0.00
30
11132
Tailwheel arm assembly With bushings

product not available CALL FOR AVAILABILITY

$301.70
31
W11011
BUSHING, 1-1/2 X 1- 5/8 X 1-1/
$16.47
32
1972
FITTING, GREASE ZERK 1/4-28
$2.93
33
25391
Tailwheel arm bracket (See note 2)

product not available CALL FOR AVAILABILITY

$62.37
34
11131
M72-3 ETC TAILWHEEL YOKE
$347.45
35
4675
WHL, 400X8 LAMINATED TIRE
$247.93
36
1040406
SHIELD KIT, PLASTIC
$164.37
37
11124
REPL BY 2 1133

product not available CALL FOR AVAILABILITY

$0.01
39
11065
Complete decal set

product not available CALL FOR AVAILABILITY

$0.01
40
12785
STUMP JUMPER
$263.90
41
8811
BLADE CARRIER, KIT CROSSBAR PU
$1,061.55
42
10899
Loctite bottle, 10 cc

product not available CALL FOR AVAILABILITY

$0.00
42
13943
Locquic - reduces setting time from 12 to 2 hrs (6 oz. spray can)

product not available CALL FOR AVAILABILITY

$0.00
43
51521
French safety decal set

product not available CALL FOR AVAILABILITY

$238.60
60
1266
PIN, COTTER 3/16 X 1-1/2
$1.44
61
744
3/8 x 2-1/2 Cotter pin (See note 4)

product not available CALL FOR AVAILABILITY

$0.00
62
21636
BOLT, 3/8 X1-1/4CLPDHDPL
$2.02
63
14350
NUT, LOCK FLANGE 3/8 NC
$1.72
64
1287
NUT WING 3/8 NC
$1.72
65
6100
BOLT, HEX 1/2 NC X 1-1/4 GR5
$2.52
66
855
WASHER, LOCK, 1/2 ZP
$1.44
67
1093
NUT, HEX HEAVY 1/2 NC ZP
$1.54
68
614
5/8 NC x 1-3/4 Hex head cap screw (See note 35)

product not available CALL FOR AVAILABILITY

$0.00
69
410
PIN CLV 5/8 X 1-3/4
$3.83
70
902
BOLT, HEX 5/8 NC X 2 GR5 ZP
$3.31
71
8099
PIN CLV 5/8 X 3-3/4 HT
$31.36
72
3097
BOLT, HEX 5/8 NC X 4-1/2 GR5 Z
$5.06
73
11043
HHCS 5/8 NC X 7-1/2 GR5
$7.22
74
3632
WASHER, FLAT, 5/8 SAE ZP
$1.44
75
692
WASHER, FLAT, 5/8 STD ZP
$1.72
76
230
NUT, HEX, 5/8 NC PLATD
$1.72
77
6239
NUT, LOCK, 5/8 NC
$2.31
78
12006
NUT STOP 5/8 NC ELASTIC
$1.90
79
4616
HHCS 3/4 NC X 1-1/2 GR5 ZP
$9.63
80
2377
BOLT, HEX 3/4 NC X 6 GR5 ZP
$8.36
81
5549
PIN CLV 3/4 X 7-3/4
$26.94
82
2864
WASHER, FLAT, 3/4, ZINC-PLT ST
$0.32
83
8371
3/4 NC Hex head (See note 16)

product not available CALL FOR AVAILABILITY

$0.00
84
5849
NUT, SLOTTED, 3/4-16 X 21/32,
$3.13
85
2370
WASHER, SPECIAL, 1.62 X 3 X .
$2.52
86
11900
NUT, LOCK FLANGE 1/2 NC
$1.90
87
3699
BOLT, HEX 1/2 NC X 2 GR5
$2.31
