Woods Woods MB61AC Multi-Spindle Cutter Main Assembly Parts List (SN 2000)

#
Part #
Item
Price
Qty
Add
1
7064
Tongue

product not available CALL FOR AVAILABILITY

$239.90
2
W07054
inchU inch frame

product not available CALL FOR AVAILABILITY

$0.00
2O
1563
C80 C080 C114SKID W/HDWR
$226.35
3
7036
Front reversible shld

product not available CALL FOR AVAILABILITY

$107.80
4
7007
Frame only

product not available CALL FOR AVAILABILITY

$0.00
5
4286
Right pin arm

product not available CALL FOR AVAILABILITY

$0.00
6
W004293
DEL- CYLINDER, 5 TON- RGD CPL
$1,407.54
7A
11015
Front Half 1-3/8 Spline (See note 19)

product not available CALL FOR AVAILABILITY

$0.00
7B
7242
Rear section of 2 & 3 joint drive (See note 8)

product not available CALL FOR AVAILABILITY

$0.00
8
609
Pin

product not available CALL FOR AVAILABILITY

$0.00
10
7309
Key

product not available CALL FOR AVAILABILITY

$0.00
11
4295
Bracket

product not available CALL FOR AVAILABILITY

$0.00
12
607RP
3/8 X 3/8 X 2-3/8 KEY

product not available CALL FOR AVAILABILITY

$3.60
13
7008
Gear stand

product not available CALL FOR AVAILABILITY

$0.00
14
419
SPR/EXT0.88 .15 4.1 107
$20.19
15
1351
Take-up rod

product not available CALL FOR AVAILABILITY

$0.00
16
2324
Rear shield

product not available CALL FOR AVAILABILITY

$193.30
17
W12162
C80ETC RIGHT V BELT SHLD
$157.57
18
W12163
C80 ETC LEFT V BELT SHLD
$157.57
19
2128
C80 ETC ANTIWNDRO BFL
$159.92
21
4910
CROSSBAR - HOUSING ASY 80
$855.00
22
1976
Sheave

product not available CALL FOR AVAILABILITY

$0.00
23
1482
BSHG P1 1-1/4 STRT BORE
$56.59
25
606
LUG 1/4 X 1-1/2 X 2

product not available CALL FOR AVAILABILITY

$81.98
26
214
Sheave

product not available CALL FOR AVAILABILITY

$0.00
27
6230
Set of 3 matched V-belts

product not available CALL FOR AVAILABILITY

$0.00
29
29038RP
C80 ETC SPINDLE SUPP PLT
$90.98
30
3444RP
ACCESS HOLE COVER
$22.22
31
4287
Left pin arm

product not available CALL FOR AVAILABILITY

$0.00
32
484
.625 X 1.00 X .438 HT SLV
$3.63
33
1791
SLEEVE, .625 X 1.00 X .563 HT
$2.52
34
7017
Floating idler arm

product not available CALL FOR AVAILABILITY

$0.00
37
7045
Leaf mulcher

product not available CALL FOR AVAILABILITY

$0.00
38
3998
Chain shielding

product not available CALL FOR AVAILABILITY

$0.00
50
1256
3/16 X 1, COTTER PIN
$1.19
51
5295
5/16 NC x 1 inch Hex head cap screw (See note 9)

product not available CALL FOR AVAILABILITY

$0.00
52
839
BOLT, HEX 3/8 NC X 1 GR5 ZP
$1.54
53
838
WASHER, LOCK, 3/8 ZP
$1.44
54
835
NUT, HEX 3/8 NC ZP
$1.72
55
1287
NUT WING 3/8 NC
$1.72
56
25475
BOLT, HEX 1/2 NC X 1 GR5 ZP FU
$2.13
57
1262RP
HHCS 1/2 NC X 1-1/4 DRL HD

product not available CALL FOR AVAILABILITY

$22.89
58
3379
BOLT, HEX 1/2 NC X 1-1/2 GR5 Z
$2.93
59
3452
HHCS 1/2 NF X 1-1/2 HT
$12.05
60
24576
HHCS 1/2 NC X 1-3/4 GR5 ZP
$2.52
61
948
1/2 NC x 2 inch Hex head cap screw (See note 3)

product not available CALL FOR AVAILABILITY

$0.00
62
854
WASHER, FLAT, 1/2 STD ZP
$1.44
63
855
WASHER, LOCK, 1/2 ZP
$1.44
64
1093
NUT, HEX HEAVY 1/2 NC ZP
$1.54
65
6241
NUT, LOCK NYLOC 1/2 NC
$1.67
66
2855
BOLT, CARRIAGE 5/8 NC X 2
$3.13
67
614
5/8 NC x 1-3/4 Hex head cap screw (See note 35)

product not available CALL FOR AVAILABILITY

$0.00
69
23141
BOLT, HEX 5/8 NC X 3-1/2 HT
$3.23
70
692
WASHER, FLAT, 5/8 STD ZP
$1.72
71
1286
WASHER, LOCK, HEAVY ZP
$1.72
72
230
NUT, HEX, 5/8 NC PLATD
$1.72
73
2864
WASHER, FLAT, 3/4, ZINC-PLT ST
$0.32
74
6238
5/8 NC x 2-1/4 Hex head cap screw (See note 23)

product not available CALL FOR AVAILABILITY

$0.00

4289
inchU inch frame

product not available CALL FOR AVAILABILITY

$0.00

3054
Anti-windrow baffle

product not available CALL FOR AVAILABILITY

$0.00

2265
Gear stand

product not available CALL FOR AVAILABILITY

$0.00

3930
Spindle & blades

product not available CALL FOR AVAILABILITY

$0.00

235
Floating idler arm

product not available CALL FOR AVAILABILITY

$0.00

1261A
Leaf mulcher

product not available CALL FOR AVAILABILITY

$0.00
